Metal Detector
X-TERRA PRO
$299.99
In stock
SKU
3707-0001
FEATURES
SIMPLE TO USE
AUDIO CONTROL
CHOICE OF COILS
LIGHTING AND VIBRATION
LOUD AND CLEAR AUDIO
BUILT TO LAST
OVERVIEW
FULLY-WATERPROOF, FULLY-LOADED TREASURE DETECTOR
X-TERRA PRO
Stand out from the crowd and step-up your detecting game with the all-new X-TERRA PRO treasure detector by Minelab. Out of the box, simply set your detector to match your terrain with Park, Field and Beach Search Modes and leave all the hard work up to the detector to start unearthing the treasure you seek
As your skills improve, X-TERRA PRO offers room to grow with PRO-SWITCH (Switchable Frequency Technology), so you can set it to 5, 8, 10, or 15 kHz at the press of a button and take control of any environment or situation that comes your way.
Fully IP68 waterproof to 16 ft and loaded with features like 5-audio modes, control pod flashlight, and handgrip vibration you’ll be detecting like a pro from the moment you start swinging.
PRO-SWITCH™
Driven by the enhanced PRO-SWITCH™ engine, X-TERRA PRO by Minelab gives you the power to switch frequencies. Detect targets deep anywhere, in any conditions — there’s deep and then there’s Minelab deep.
SEARCH MODES
Choose between 2 x Park, 2 x Field and 2 x Beach pre-programmed Search Modes. No terrain is off limits.
FULLY WATERPROOF
With waterproof control pod and coil to 16 ft, take X-TERRA PRO anywhere — land or water — and own the ground beneath your feet.
1 Power ON/OFF
2 Backlight & Flashlight Settings
3 Backlit Keys for Night Mode
4 Detect Mode Button
5 All-Metal Shortcut
6 Pinpoint/Detect Button
7 Wireless Audio Control
8 Sensitivity & Setting Control
9 Accept / Reject Button
10 Frequency Select Button
BEACH PERFORMANCE
X-TERRA PRO by Minelab dominates at the beach and a dedicated Beach Mode handles the most difficult saltwater conditions.
1 Built-in Speaker
2 Flashlight
3 3.5 MM Headphone Socket
with Waterproof Cap
4 Low Latency Wireless Audio
5 Magnetic USB Charging
Connector
6 Adjustable Handgrip
7 Handgrip Vibration
LIGHT AND COMPACT
Comprising lightweight 3-piece shafts, X-TERRA PRO weighs only 2.9 lb and packs down to a mere 25 inches — throw it in your backpack and you’re all set.
SIMPLE TO USE
A large LCD display and intuitive user interface makes it easy for beginners to get started right out the box, and seasoned hunters to fine-tune settings quickly and easily.
ADVANCED AUDIO CONTROL
With multiple tone audio options, the sound of treasure has never been clearer — X-TERRA PRO’s advanced audio means you’ll not only ‘hear’ if a target is trash or treasure but you’ll also be able to gauge its size and depth simply by listening.
CHOICE OF COILS
X-TERRA PRO by Minelab offers an array of waterproof coils and is compatible with V12X™ 12"x9" Elliptical Double-D (included), V8X™ 8"x5" Elliptical Double-D, and V10X™ 10"x7" Elliptical Double-D coils (accessory) so you’ll be prepared for any terrain. X-TERRA PRO is also compatible with all EQUINOX® series coils.
LIGHTING AND VIBRATION
The daylight may have ended, but that doesn’t mean your hunt has to — with Control Pod Flashlight, Red Backlight Display, Backlit Keypad, and Handgrip Vibration you can power on long after the sun has gone.
LOUD AND CLEAR AUDIO
Enjoy the crystal-clear audio with In-Built Speaker (included) or lightning-fast Low Latency Wireless Headphones, Wired Headphones, and Waterproof Headphones (accessories).
BUILT TO LAST
Because we’re committed to leading the pack for performance and support, X-TERRA PRO by Minelab is backed by Minelab’s global network and up to 3-year warranty.
ACCESSORIES INCLUDED
V12X™ DOUBLE-D COIL
TECHNICAL SPECIFICATIONS
SEARCH MODES
Park, Field, Beach
ALL METAL SHORTCUT
YES
CUSTOM SEARCH PROFILES
6
OPERATING FREQUENCIES (kHz)
Park and Field: 5, 10, 15 | Beach: 8
NOISE CANCEL
Auto (19 Channels)
GROUND BALANCE
Auto | Manual | Tracking
SENSITIVITY
1 to 25
TARGET VOLUME
0 to 25
THRESHOLD LEVEL
0 to 25
THRESHOLD PITCH
Fixed
TARGET IDENTIFICATION (TID)
119 segment notch discrimination: Ferrous: -19 to 0 | Non-ferrous: 1 to 99
TARGET TONES
1 | 2 | 5 | All Tones (At) | Depth (dP)
TONE BREAK
Ferrous (t1)
TONE VOLUME
Tone 1 adjustable: 0 to 25
RECOVERY SPEED
1 to 3
DEPTH INDICATOR
5 levels
DISCRIMINATION SEGMENTS
30 segments (in increments of 4 Target IDs)
PINPOINT MODE
YES
WIRELESS AUDIO
Yes
LENGTH (APPROX)
Collapsed: 25 in. ( 630 mm ) Extended: 54 in. ( 1380 mm )
WEIGHT
2.9 lbs ( 1.3 kg )
DISPLAY
Monochrome LCD
DISPLAY AND KEYPAD BACKLIGHT (RED)
Off | High | Low
FLASHLIGHT
On | Off
VIBRATION (MASTER AND FERROUS)
On | Off
SUPPLIED COIL
V12X 12" Double-D Elliptical coil with skid plate
AUDIO OUTPUT
In-built loudspeaker, Wired 3.5 mm (⅛") headphones, Wireless headphones
BATTERY
3.7 V / 5100 mAh Internal Lithium-Ion battery
ADDITIONAL INCLUDED ACCESSORIES
Getting Started Guide, Charging Cable
WATERPROOF
Waterproof to 16 ft / 5 m , IP68
OPERATING TEMPERATURE RANGE
+14°F to +104°F ( –10°C to +40°C )
STORAGE TEMPERATURE RANGE
–20°C to +70°C (–4°F to +158°F)
KEY TECHNOLOGIES
Pro-Switch™
FAQ
How does X-TERRA PRO work?
The X-TERRA PRO is a versatile, feature-packed metal detector that stands out in the world of detectorism. One of its main differentiators is PRO-SWITCH, a switchable frequency technology that allows you to adjust the detector to 5, 8, 10 or 15 kHz with the simple touch of a button. This offers flexibility and full control in different environments and detection situations. Additionally, the X-TERRA PRO is water resistant, IP68 certified, meaning it can be submerged up to 5 meters (16 feet). This allows detectors to explore water areas with confidence. The X-TERRA PRO coil is designed to provide excellent detection performance. It is capable of detecting a variety of targets, including relics, gold, jewelry, and more. Its sensitivity and deep target detection capabilities make it suitable for a wide range of applications. So no matter what terrain you're detecting in, the X-TERRA PRO is prepared to meet the challenge. Its robustness and advanced features make it a reliable and efficient metal detector for enthusiasts and professionals alike.
What are the benefits and features of the X-TERRA PRO metal detector?
Come with us and check out the main benefits and features of the X-TERRA PRO metal detector.
Vibration systems - Minelab X-TERRA PRO offers vibration, lighting and sound signaling systems to assist you during your searches. With the control module and flashlight, red backlit panel and display, and backlight keys, you can continue detecting even after dark. Additionally, vibration in the grip provides an additional form of feedback.
Sound Signaling - The detector features an advanced audio system, with a high-quality built-in speaker and adjustable tone audio options. This allows for more accurate detection, making it possible to identify the type of target and even estimate its size and depth just by sound.
Lightweight and compact - The X-TERRA PRO is lightweight and compact, weighing just 1.3 kg (2.9 lb) and can be collapsed to just 63 cm (25 in). This makes it easy to transport and store, making it ideal for detection adventures.
Simple to Use - The intuitive user interface and large LCD display make the detector easy to use for both beginners and experienced hunters. You can start using the X-TERRA PRO right away or adjust its settings with ease.
Choice of Coils - The X-TERRA PRO offers waterproof coil options, including the V12X™ 12"X9" Elliptical Double-D (included), the V8X™ 8"x5" Elliptical Double-D, and the V10X™ 10"X7" Double-D elliptical, in addition to being compatible with all coils in the EQUINOX® series. This allows you to choose the most suitable coil for each type of terrain, ensuring efficient results in your searches.
What is Pro-Switch technology?
PRO-SWITCH technology is the latest single-frequency VLF technology that allows the user to switch transmission frequencies to optimize performance. It gives detectorists the ability to adjust frequencies to move away from noise or optimize detection capability when searching for specific metallic targets. Park and Field modes include selectable frequencies of 5kHz, 10kHz and 15kHz. Beach modes include a single 8 kHz frequency for high salt mineralization.
Is Multi-IQ technology better than Pro-Switch technology?
In most detection situations, MULTI-IQ will provide superior results when compared to PRO-SWITCH. There may be situations where PRO-SWITCH technology can work as well as MULTI-IQ. This will depend on how the user has optimized the detector settings. Multi-IQ will provide maximum performance in all situations as the internal processor does all the hard work. PRO-SWITCH relies on the user to ensure the detector is configured for its optimal performance capability
Is the Minelab X-TERRA PRO metal detector waterproof?
Yes, the Minelab X-TERRA PRO metal detector is waterproof. Both the control box and coil can be submerged up to 5 meters (16 feet) deep. This means you can take it anywhere, explore underwater areas, and enjoy metal detecting in aquatic environments with complete confidence. Therefore, if you are looking for a waterproof metal detector, the X-TERRA PRO is a great choice. Additionally, it has a dedicated beach mode designed to handle the challenging saltwater conditions at the beach, ensuring efficient and accurate performance.
Can I use the Original X-Terra coils on the X-Terra Pro?
EQUINOX series coils can be used with the X-TERRA PRO, but no other Minelab brand coils can be used, including previous X-TERRA 30, 50, 70, 305, 505 and 705 series coils.
What coils can be used on the X-Terra Pro?
The X-TERRA PRO comes with a 12” Double-D V12X elliptical coil in the box, but you can also purchase the accessory coils below on Minelab’s e-commerce.
8" V8X Double-D Elliptical Coil (3011-0457)
10" Double-D V10X Elliptical Coil (3011-0458)
12" Double-D V12X Elliptical Coil (3011-0459)
EQX06 / EQX|06 (6” Double-D round coil) (3011-0333)
EQX11 / EQX|11 (11” Double-D round coil) (3011-0334)
EQX15 / EQX|15 (15”x12” Double-D coil) (3011-0335)
How does the X-Terra Pro's performance compare to the Vanquish series?
The X-TERRA PRO is a solid single frequency performance detector that has the ability to switch frequencies without the need to change hardware. Performance is similar in some circumstances, but will differ depending on soil mineralization levels, but more specifically the composition of each target and the frequency the X-TERRA PRO is transmitting. Target ID numbers are generally not as stable as MULTI-IQ target ID numbers.
What frequency should I choose when detecting with the X-Terra Pro?
This will depend on what targets you want to find. It is expected that when running a lower transmit frequency on the X-TERRA PRO, performance on high conductors containing silver or copper will provide similar depths to MULTI-IQ detectors. , when running a higher transmit frequency in the X-TERRA PRO, performance on lower gold-containing conductors provides similar depths to MULTI-IQ detectors.
How does the X-Terra Pro perform on the beach or in salty conditions?
On the beach, in salty conditions, most single-frequency detectors struggle with mineralization. The X-TERRA PRO offers unprecedented performance for a single frequency VLF detector in salty conditions.
Can I use wireless headphones with my X-Terra Pro?
Yes, you can buy the Minelab ML85 or ML105 headphones as they are both compatible with the X-TERRA PRO.
What are the differences between the detection mode search profiles?
Park 1 provides a standard transmission frequency of 10 kHz and is optimized for detecting modern coins and larger jewelry. This is a good way to learn the X-TERRA PRO before experimenting with other settings.
Park 2 provides a standard transmission frequency of 15 kHz and is optimized for detecting fine jewelry and smaller targets in trash-infested areas. The recovery speed in Park 2 is increased to clearly identify good targets masked by iron junk.
Field 1 provides a standard transmission frequency of 10 kHz and is optimized for modern coin detection and general detection. It has high impurity rejection, making it an ideal detection mode for areas containing coke.
Field 2 provides a standard transmission frequency of 15 kHz and is optimized for locations with high densities of targets and trash. This mode is great for coins on the edge or at great depths. It has high impurity rejection, making it an ideal detection mode for areas containing coke.
Beach 1 provides a standard transmission frequency of 8 kHz and is optimized for dry and wet sand. Beach 1 mode has a slower retrieval speed for better depth on all targets and is good for detecting small to large coins and jewelry.
The Beach 2 provides a standard transmission frequency of 8 kHz and is optimized for underwater use where a very strong salt signal is present. To compensate for the high salt content, Beach 2 has a lower transmission power. Beach 2 has a higher recovery speed to help with saltwater rejection. It can also be used on dry and heavily mineralized soils
How long does the lithium-ion battery last on a single charge?
Typical runtime from a full charge using wired headphones is approximately 16 hours. The X-TERRA PRO detector can also be powered directly from any USB Power Bank that supports 0.5A or 2A (@5V) output capability. This effectively provides continuous runtime limited only by the capacity of the power bank.
Should I wash my X-Terra Pro detector after using it at the beach?
Yes. It is good practice to wash the detector with clean, fresh water after detecting in the water or at the beach. Never use abrasives or solvents to clean the detector. Whenever washing or using your detector underwater, always make sure the plastic cap on the back of the control pod is screwed securely onto the earpiece.
What are the accessories of the X-TERRA PRO metal detector?
The X-TERRA PRO metal detector comes with some accessories included. Are they:.
V12X™ Coil: A 12"x9" elliptical coil with reinforcement plate, designed to provide exceptional detection performance. This coil is waterproof and can be submerged up to 5 meters (16 feet);
Charger cable: a charging cable to power the detector's battery and ensure its continuous operation;
Start-up guide: a printed getting started guide that provides basic information and guidance for starting to use the equipment.
In addition to these included accessories, it is possible to further improve detection by purchasing separate accessories for the X-TERRA PRO. For example, you can purchase additional coils compatible with the detector, such as the V12X™ coil or other options available from Minelab. Discover the accessories to purchase additionally directly on the Minelab website.
Detect in water. Which headphones should I use?
In deep water or fully submerged, we recommend using only Minelab waterproof headphones. They have a specially designed connector that forms a waterproof seal when used with the X-TERRA PRO. These headphones are available as accessories (Part Number: 3011-0372).
